66PCE Heat Shrink Tube Kit / Item No: S0266KC1

  • S0266KC1
Heat Shrink Series

66PCE Heat Shrink Tube Kit / Item No: S0266KC1

Heat shrink tubing, also known as heat shrink, is a shrinkable tube that shrinks radially when exposed to heat. Produced using a two-step process, heat shrink is available in a wide range of materials to suit almost any application. Heat shrink tubing has many useful applications, including to provide electrical insulation to wires, connections, joints, terminals, and splices, as well as bundling loose items such as wires and as a protective covering.

Product Introduction

Item No: S0266KC1    66PCE Heat Shrink Tube Kit

  • Dual Wall Heat Shrink Tube - Black
  • Heat Shrink Tin Butt Connector - Red
  • Heat Shrink Tin Butt Connector - Blue
  • Heat Shrink Tin Butt Connector - Yellow
  • Heat Shrink Tin Butt Connector - Clear
  • Flameless Heat Blower



Heat shrink tubing, also known as heat shrink, is a shrinkable tube that shrinks radially when exposed to heat. Produced using a two-step process, heat shrink is available in a wide range of materials to suit almost any application. Heat shrink tubing has many useful applications, including to provide electrical insulation to wires, connections, joints, terminals, and splices, as well as bundling loose items such as wires and as a protective covering.



Heat Shrink Tin Butt Connector:

Terminal Material: Tin

Insulation Material: PE

  1. Operating Temperature: -40°C~ +105°C
  2. Shrink Ratio: 3:1
  3. Maximum Electrical Rating: 600 Volts
  4. Waterproof



Dual Wall Heat Shrink Tube:

Material: Polyolefin

  1. Operating Temperature: -45°C~ +125°C
  2. Shrink Temperature: Start at 70°C ; Shrunk totally at 125°C
  3. Shrink Ratio: 3:1
  4. Maximum Electrical Rating: 600 Volts
  5. Waterproof



Flameless Heat Blower:

Specification:

  1. Fuel: Butane
  2. Gas container capacity: 6 ml
  3. Operating time: 20 minutes
  4. Approximate Temperature: Up to 450°C



Features:

  1. Protection and insulation of components and wires.
  2. Adhesive Lined inner wall seals and protects against moisture ingress preventing corrosion.
  3. Quickly & simply shrink by Heat gun.
  4. Waterproof



  • Great variety of top pro-quality heat shrink tubing.Heat activated adhesive lining provides impermeable seal to salt water and other liquids.
  • Includes handy plastic container for easy organization and storage.
  • 3:1 heat shrink ratio. Will shrink up to 1/3 of original diameter.
